G100H DCNLEV100 100A 1NO DC High Voltage EV Relay 12V to 750V or 900V DC Contact 12Vdc 24Vdc Coil 100A High Voltage DC Contactor
$ 22.50
Description Place of Origin : China Brand Name : OEM brand Model Number : G100H Electricity Type : DC Number of Pole : 1 Phase : 1 Main Circuit Rating Voltage : 12Vdc or 24Vdc Main Circuit Rating Current : 100A Contact Voltage Rating : 12 – 900V DC Coil Voltage : 12V DC, 24V DC Rated Current : 100A Contact Form : SPST-NO G100H DCNLEV100 100A 1NO DC High Voltage EV Relay 12V to 750V or 900V DC Contact 12Vdc 24Vdc Coil 100A High Voltage DC Contactor 100A High Voltage DC Contactor Features: DC 12-900V rated load voltage of contact circuit. SPST-NO of contact form, 12 volt, 24 volt coil for selecting. Main contact voltage drop at 100A, not above 100mV. The connection of contact and coil need to be nonpolarity. Efficient coil, retentive power is only 2-2.3W, counter electromotive force is 0V. The joint way of the coil is very convenient. The coil has no counter force of electromagnetism. Compare to the similar products, this product is smallest and lightest. 100A High Voltage DC Contactor Specifications: Model G50H G100H G150H G200H G250H G300H Rated Current 50A 100A 150A 200A 250A 300A Contact type SPST NO Contact rated voltage & current 12-900Vdc Coil voltage 12Vdc, 24Vdc, 48Vdc Coil power consumption ≤6W Output Connectors M5 Bolt and Lockwasher Connections Connectors Wire Leads for Control Circuit Pickup voltage ≤75%Us Release voltage ≤7Vdc Pickup time ≤30ms Release time ≤20ms Electric life (450Vdc) ≥5000 times Electric life (750Vdc) ≥2000 times ≥1000 times Electric life (900Vdc) ≥2000 times ≥1000 times Ingress Protections IP67 Working temperature -40 to 85°C 100A High Voltage DC Contactor Electric Diagram: 100A High Voltage DC Contactor Dimension:
